D 11 47
m
When fitted with SW6500:
Every time after restarting the vehicle, the main conveyor has to be moved into its up-
per end position when starting up the conveying function for the first time or when ac-
tuating functions (43-46) / (131-134)!
Function buttons (47) and (48) are then deactivated until the next restart.
Item Designation Brief description
63
Fill vehicle for con-
veying process
Detent switch function and LED feedback:
- Filling function for the conveying process.
The diesel engine's speed is increased to the preselected
nominal speed and all functions set to "Automatic"
are engaged.
A
The main function switch must be set to the OFF position.
- Switch OFF by pressing the button again or by swivel-
ling the drive lever out to the paving position.
- On reaching the adjusted material height (material sen-
sor), the filling function is automatically switched off.
f
On actuation, heed danger zones of moving parts of
the vehicle!
64 Set-up mode
Detent switch function and LED feedback:
- When the vehicle is stationary, this function enables
all operating functions, which are only activated when
the drive lever is swivelled out (vehicle driving), to be
started up.
A
The main function switch must be set to the OFF position.
A
The engine speed is increased to the preselected nomi-
nal value.
