D 11 59
Item Designation Brief description
100
Emergency stop
button
In the case of an emergency (danger to persons, possible col-
lision, etc.), press the button!
- Pressing the emergency stop button switches off the engi-
ne, the drives and the steering system.
Making way, moving the conveyor belt, etc. is then no lon-
ger possible! Danger of accident!
- To restart the engine, the button must be pulled out again.
101 Open hopper left
Pushbutton function:
- To open the left hopper lid + front hopper.
f
On actuation, heed danger zones of moving parts of
the vehicle!
102 Close hopper left
Pushbutton function:
- To close the left hopper lid + front hopper.
f
On actuation, heed danger zones of moving parts of
the vehicle!
103 Open hopper right
Pushbutton function:
- To open the right hopper lid + front hopper.
f
On actuation, heed danger zones of moving parts of
the vehicle!
104 Close hopper right
Pushbutton function:
- To close the right hopper lid + front hopper.
f
On actuation, heed danger zones of moving parts of
the vehicle!
