D 11 77
m
When fitted with SW6500:
Every time after restarting the vehicle, the main conveyor has to be moved into its up-
per end position when starting up the conveying function for the first time or when ac-
tuating functions (43-46) / (131-134)!
Function buttons (47) and (48) are then deactivated until the next restart.
Item Designation Brief description
125
Drive and function
lever (joystick)
For engaging the feeder functions and continuously regulating
the vehicle speed – forward or reverse.
Centre position: Engine in neutral; no travel drive;
- Press release button (126) to swivel out.
- Engagement of the conveying functions
set to "AUTO"!
A
Use the preselector on the operating panel to set the
maximum speed.
f
The vehicle speed cannot be reduced to "0" with the
preselector. The vehicle advances slightly with deflec-
ted drive lever, even if the travel drive preselector is
set to zero!
A
If the engine is started with the drive lever swivelled, the
travel drive is blocked.
To be able to start the travel drive, the drive lever must
first be returned to the centre position.
A
When changing over between forwards and reverse tra-
vel, the drive lever must remain briefly in neutral.
126 Release button
- Must be pressed to release the travel drive with deflected
drive lever.
127
Main conveyor
belt + slewing
conveyor belt -
delivery
capacity + / -
Rotary switch:
- for adjusting the conveying rate from max. to min. rate.
- turning "upwards": increase conveying rate.
- turning "downwards": reduce conveying rate.
128 Horn
Press in the case of emergencies and to indicate when the ve-
hicle starts to move!
A
The horn can also be used to communicate acoustical-
ly with the truck driver for material loading!
