MAP and VFR GPS Navigator Operation
5-14 SkyView HDX Pilot’s User Guide – Revision B
Airspace Type
Color
Example
Class A
Solid orange with interior
shading. Not depicted in the
US, where all airspace above
FL180 is Class A
Class B
Solid dark blue with interior
shading
Class C
Solid dark magenta with
interior shading
Class D
Dashed light blue
Class E
(only those areas that
extend to the surface in
US depictions)
Solid green with interior
shading
