C
HAPTER
5
| Interface Configuration
Trunk Configuration
– 153 –
WEB INTERFACE
To display LACP port counters:
1. Click Interface, Trunk, Dynamic.
2. Select Configure Aggregation Port from the Step list.
3. Select Show Information from the Action list.
4. Click Counters.
5. Select a group member from the Port list.
Figure 49: Displaying LACP Port Counters
Marker Unknown Pkts Number of frames received that either (1) Carry the Slow
Protocols Ethernet Type value, but contain an unknown PDU, or
(2) are addressed to the Slow Protocols group MAC Address, but
do not carry the Slow Protocols Ethernet Type.
Marker Illegal Pkts Number of frames that carry the Slow Protocols Ethernet Type
value, but contain a badly formed PDU or an illegal value of
Protocol Subtype.
Table 8: LACP Port Counters (Continued)
Parameter Description
