C
HAPTER
15
| Basic Administration Protocols
Switch Clustering
– 420 –
MANAGING CLUSTER
MEMBERS
Use the Administration > Cluster (Show Member) page to manage another
switch in the cluster.
CLI REFERENCES
â—† "Switch Clustering" on page 563
PARAMETERS
These parameters are displayed:
◆ Member ID – The ID number of the Member switch. (Range: 1-36)
◆ Role – Indicates the current status of the switch in the cluster.
◆ IP Address – The internal cluster IP address assigned to the Member
switch.
◆ MAC Address – The MAC address of the Member switch.
◆ Description – The system description string of the Member switch.
◆ Operate – Remotely manage a cluster member.
WEB INTERFACE
To manage a cluster member:
1. Click Administration, Cluster.
2. Select Show Member from the Step list.
3. Select an entry from the Cluster Member List.
4. Click Operate.
Figure 251: Managing a Cluster Member
