C
HAPTER
15
| Basic Administration Protocols
Link Layer Discovery Protocol
– 370 –
This parameter only applies to SNMP applications which use data stored
in the LLDP MIB for network monitoring or management.
Information about changes in LLDP neighbors that occur between SNMP
notifications is not transmitted. Only state changes that exist at the
time of a notification are included in the transmission. An SNMP agent
should therefore periodically check the value of
lldpStatsRemTableLastChangeTime to detect any lldpRemTablesChange
notification-events missed due to throttling or transmission loss.
WEB INTERFACE
To configure LLDP timing attributes:
1. Click Administration, LLDP.
2. Select Configure Global from the Step list.
3. Enable LLDP, and modify any of the timing parameters as required.
4. Click Apply.
Figure 209: Configuring LLDP Timing Attributes
CONFIGURING LLDP
I
NTERFACE
ATTRIBUTES
Use the Administration > LLDP (Configure Interface) page to specify the
message attributes for individual interfaces, including whether messages
are transmitted, received, or both transmitted and received, whether SNMP
notifications are sent, and the type of information advertised.
CLI REFERENCES
â—† "LLDP Commands" on page 933
PARAMETERS
These parameters are displayed:
◆ Admin Status – Enables LLDP message transmit and receive modes
for LLDP Protocol Data Units. (Options: Tx only, Rx only, TxRx,
Disabled; Default: TxRx)
