C
HAPTER
35
| VLAN Commands
Configuring IEEE 802.1Q Tunneling
– 845 –
COMMAND MODE
Interface Configuration (Ethernet, Port Channel)
COMMAND USAGE
â—† Use the switchport dot1q-tunnel tpid command to set a custom
802.1Q ethertype value on the selected interface. This feature allows
the switch to interoperate with third-party switches that do not use the
standard 0x8100 ethertype to identify 802.1Q-tagged frames. For
example, 0x1234 is set as the custom 802.1Q ethertype on a trunk
port, incoming frames containing that ethertype are assigned to the
VLAN contained in the tag following the ethertype field, as they would
be with a standard 802.1Q trunk. Frames arriving on the port
containing any other ethertype are looked upon as untagged frames,
and assigned to the native VLAN of that port.
â—† All ports on the switch will be set to the same ethertype.
EXAMPLE
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel tpid 9100
Console(config-if)#
RELATED COMMANDS
show interfaces switchport (732)
show dot1q-tunnel This command displays information about QinQ tunnel ports.
SYNTAX
show dot1q-tunnel [interface interface [service svid] |
service [svid]]
interface
ethernet unit/port
unit - Stack unit. (Range: 1)
port - Port number. (Range: 1-10)
port-channel channel-id (Range: 1-5)
svid - VLAN ID for the outer VLAN tag (SPVID). (Range: 1-4093, no
leading zeroes)
COMMAND MODE
Privileged Exec
EXAMPLE
Console(config)#dot1q-tunnel system-tunnel-control
Console(config)#interface ethernet 1/1
Console(config-if)#switchport dot1q-tunnel mode access
Console(config-if)#interface ethernet 1/2
Console(config-if)#switchport dot1q-tunnel mode uplink
