– 51 –

S

ECTION

I

GETTING STARTED

This section provides an overview of the switch, and introduces some basic

concepts about network switches. It also describes the basic settings

required to access the management interface.

This section includes these chapters:

◆ "Introduction" on page 53

◆ "Initial Switch Configuration" on page 63
