C
HAPTER
27
| Interface Commands
– 734 –
COMMAND USAGE
The switch can display diagnostic information for SFP modules which
support the SFF-8472 Specification for Diagnostic Monitoring Interface for
Optical Transceivers. This information allows administrators to remotely
diagnose problems with optical devices. This feature, referred to as Digital
Diagnostic Monitoring (DDM) in the command display, provides information
on transceiver parameters including temperature, supply voltage, laser
bias current, laser power, received optical power, and related alarm
thresholds.
EXAMPLE
Console#show interfaces transceiver ethernet 1/10
Information of Eth 1/10
Connector Type : LC
Fiber Type : [0x00]
Eth Compliance Codes : 1000BASE-ZX
Baud Rate : 1300 MBd
Vendor OUI : 00-00-5F
Vendor Name : SumitomoElectric
Vendor PN : SCP6G94-FN-BWH
Vendor Rev : Z
Vendor SN : SE08T712Z00006
Date Code : 10-09-14
DDM Info
Temperature : 35.64 degree C
Vcc : 3.25 V
Bias Current : 12.13 mA
TX Power : 2.36 dBm
RX Power : -24.20 dBm
DDM Thresholds
High Alarm High Warning Low Warning Low Alarm
----------- ------------ ------------ ------------ ------------
Temperature(Celsius) 97.00 95.00 -83.00 -83.00
Voltage(Volts) 4.00 3.60 3.00 2.80
Current(mA) 70.00 60.00 0.00 0.00
TxPower(dBm) 8.00 6.00 -1.00 -3.00
RxPower(dBm) -3.00 -3.50 -21.00 -21.50
Console#
test cable-
diagnostics
This command performs cable diagnostics on the specified port to diagnose
any cable faults (short, open, etc.) and report the cable length.
SYNTAX
test cable-diagnostics interface interface
interface
ethernet unit/port
unit - Unit identifier. (Range: 1)
port - Port number. (Range: 1-10)
COMMAND MODE
Privileged Exec
