C
HAPTER
35
| VLAN Commands
Configuring Port-based Traffic Segmentation
– 846 –
Console(config-if)#end
Console#show dot1q-tunnel
Current double-tagged status of the system is Enabled
The dot1q-tunnel mode of the set interface 1/1 is Access mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/2 is Uplink mode, TPID is 0x8100.
The dot1q-tunnel mode of the set interface 1/3 is Normal mode, TPID is 0x8100.
.
.
.
Console#show dot1q-tunnel interface ethernet 1/5
802.1Q Tunnel Service Subscriptions
Port Match C-VID S-VID Remove C-Tag
-------- ----------- ----- ------------
Eth 1/ 5 1 100 Disabled
Console#show dot1q-tunnel service 100
802.1Q Tunnel Service Subscriptions
Port Match C-VID S-VID Remove C-Tag
-------- ----------- ----- ------------
Eth 1/ 5 1 100 Disabled
Eth 1/ 6 1 100 Enabled
Console#
RELATED COMMANDS
switchport dot1q-tunnel mode (842)
CONFIGURING PORT-BASED TRAFFIC SEGMENTATION
If tighter security is required for passing traffic from different clients
through downlink ports on the local network and over uplink ports to the
service provider, port-based traffic segmentation can be used to isolate
traffic for individual clients.
traffic-segmentation This command enables traffic segmentation globally, or configures the
uplink and down-link ports for a segmented group of ports. Use the no
form to disable traffic segmentation globally.
SYNTAX
[no] traffic-segmentation [uplink interface-list
downlink interface-list]
uplink – Specifies an uplink interface.
downlink – Specifies a downlink interface.
Table 115: Commands for Configuring Traffic Segmentation
Command Function Mode
traffic-segmentation Enables and configures traffic segmentation GC
show traffic-
segmentation
Displays the configured traffic segments PE
