C
HAPTER
3
| Using the Web Interface
Navigating the Web Browser Interface
– 86 –
MAIN MENU Using the onboard web agent, you can define system parameters, manage
and control the switch, and all its ports, or monitor network conditions. The
following table briefly describes the selections available from this program.
Table 6: Switch Main Menu
Menu Description Page
System
General Provides basic system description, including contact information 99
Switch Shows the number of ports, hardware version, power status, and
firmware version numbers
100
IP Sets IPv4 address for management interface and gateway 425
Configure Global Sets IP address of the gateway router between this device and
management stations that exist on other network segments
425
Configure Interface Configures IP address for management access 426
Add Sets the IPv4 address for management access 426
Show Shows the IPv4 address for management access 426
Capability Enables support for jumbo frames;
shows the bridge extension parameters
102,
103
File 104
Copy Allows the transfer and copying files 104
Set Startup Sets the startup file 107
Show Shows the files stored in flash memory; allows deletion of files 108
Automatic Operation Code Upgrade Automatically upgrades operation code if a newer version is
found on the server
109
Time 113
Configure General
Manual Manually sets the current time 113
SNTP Configures SNTP polling interval 114
Configure Time Server Configures a list of SNTP servers 115
Configure Time Zone Sets the local time zone for the system clock 116
Console Sets console port connection parameters 117
Telnet Sets Telnet connection parameters 119
CPU Utilization Displays information on CPU utilization 120
Memory Status Shows memory utilization parameters 121
Reset Restarts the switch immediately, at a specified time, after a
specified delay, or at a periodic interval
122
Interface 127
Port 127
General
Configure by Port List Configures connection settings per port 127
Configure by Port Range Configures connection settings for a range of ports 130
Show Information Displays port connection status 131
