C
HAPTER
15
| Basic Administration Protocols
Simple Network Management Protocol
– 404 –
WEB INTERFACE
To configure trap managers:
1. Click Administration, SNMP.
2. Select Configure Trap from the Step list.
3. Select Add from the Action list.
4. Fill in the required parameters based on the selected SNMP version.
5. Click Apply
Figure 233: Configuring Trap Managers (SNMPv1)
Figure 234: Configuring Trap Managers (SNMPv2c)
