C HAPTER 5 | Interface Configuration
Trunk Configuration
– 147 –
Figure 40: Configuring Connection Parameters for a Static Trunk
To display trunk connection parameters:
1. Click Interface, Trunk, Static.
2. Select Configure General from the Step list.
3. Select Show Information from the Action list.
Figure 41: Showing Information for Static Trunks
CONFIGURING A
DYNAMIC TRUNK
Use the Interface > Trunk > Dynamic (Configure Aggregator) page to set
the administrative key for an aggregation group, enable LACP on a port,
and configure protocol parameters for local and partner ports.
Figure 42: Configuring Dynamic Trunks
CLI REFERENCES
◆ "Link Aggregation Commands" on page 739
COMMAND USAGE
◆ To avoid creating a loop in the network, be sure you enable LACP before
connecting the ports, and also disconnect the ports before disabling
LACP.
active
links
}
}
dynamically
enabled
configured
members
backup
link
