C
HAPTER
19
| Using the Command Line Interface
Entering Commands
– 494 –
◆ Interface Configuration - These commands modify the port
configuration such as speed-duplex and negotiation.
◆ Line Configuration - These commands modify the console port and
Telnet configuration, and include command such as parity and
databits.
◆ Multiple Spanning Tree Configuration - These commands configure
settings for the selected multiple spanning tree instance.
◆ Policy Map Configuration - Creates a DiffServ policy map for multiple
interfaces.
◆ Time Range - Sets a time range for use by other functions, such as
Access Control Lists.
◆ VLAN Configuration - Includes the command to create VLAN groups.
To enter the Global Configuration mode, enter the command configure in
Privileged Exec mode. The system prompt will change to
“Console(config)#” which gives you access privilege to all Global
Configuration commands.
Console#configure
Console(config)#
To enter the other modes, at the configuration prompt type one of the
following commands. Use the exit or end command to return to the
Privileged Exec mode.
Table 36: Configuration Command Modes
Mode Command Prompt Page
Access
Control List
access-list arp
access-list ip standard
access-list ip extended
access-list ipv6 standard
access-list ipv6 extended
access-list mac
Console(config-arp-acl)
Console(config-std-acl)
Console(config-ext-acl)
Console(config-std-ipv6-acl)
Console(config-ext-ipv6-acl)
Console(config-mac-acl)
715
698
698
704
704
710
CFM ethernet cfm domain Console(config-ether-cfm) 966
Class Map class-map Console(config-cmap) 878
ERPS erps domain Console(config-erps) 815
Interface interface {ethernet port |
port-channel id| vlan id}
Console(config-if) 720
Line line {console | vty} Console(config-line) 535
MSTP spanning-tree mst-configuration Console(config-mstp) 790
Policy Map policy-map Console(config-pmap) 881
Time Range time-range Console(config-time-range) 560
VLAN vlan database Console(config-vlan) 831
