HAPTER

| VLAN Configuration

Configuring VLAN Mirroring

– 194 –

WEB INTERFACE

To configure VLAN mirroring:

1. Click VLAN, Mirror.

2. Select Add from the Action list.

3. Select the source VLAN, and select a target port.

4. Click Apply.

Figure 81: Configuring VLAN Mirroring

To show the VLANs to be mirrored:

1. Click VLAN, Mirror.

2. Select Show from the Action list.

Figure 82: Showing the VLANs to Mirror
