4.6 Configuring the Login-Related Settings
100
4.6.5 Setting the LAN Manager Authentication
Level
Set the LAN Manager authentication level for connecting the scanner to a server.
The LAN Manager authentication level setting is enabled in the following cases:
 The login LDAP server type is set to [Active Directory] or [Active Directory Global
Catalog], and the scanner is connected to an Active Directory server for logging in
to the scanner
 The scanner is connected to a file server for saving the scanned images in a
network folder
 The scanner is connected to a print server for printing the scanned images
For details about the LAN Manager authentication level, refer to the manual of the related
server.
1. Select [LAN Manager authentication level] under [Login Settings].
 The [LAN Manager authentication level] window appears.
2. Set the LAN Manager authentication level.
3. Press the [OK] button.
 The information entered is set.
Touch
Panel
Central Admin
Console
ATTENTION
 Setting the LAN Manager authentication level according to the server side settings is
recommended.
 Check the LAN Manager authentication level set on the server side with the server
administrator before changing the level. If a level different from the level on the server side is
set, logging in to the scanner, saving data in the network folder or printing data may be
disabled.

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
