Fujitsu N7100 User Manual

5.11 Editing the Scanned Data in the Scan Viewer
319
3. Press to show the page you want to check.
■ Changing the Display Size of Scanned Data
The display size of the scanned data shown on the scan viewer details window can be
changed to the same magnification or to fit the preview window.
1. Display a page to be checked.
2. Press to change the display.
5.11.3 Editing Scanned Data on the Scan Viewer Details Window
The scanned data can be edited one by one on the scan viewer details window.
■ Rotating Scanned Data
The scanned data displayed on the scan viewer details window can be rotated by 90
degrees.
The rotated scanned data is sent by e-mail or fax and is printed or saved to the network
folder as it is.
1. Display a page to be rotated.
2. Press to rotate.
HINT
Editing on the touch panel can also be done by using fingers. Place two fingers on the
scanned data, and pinch out (zoom in) and pinch in (zoom out).
HINT
 The scanned data is edited once a page is rotated.
 Editing on the touch panel can also be done by using fingers on the touch panel. Put two
fingers on the scanned data and turn your fingers (clockwise/counterclockwise).

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
