6.1 Cleaning Supplies and Parts to Clean

343

■ Which Parts and When

Part to Clean Cleaning Frequency

Brake roller Clean after every 1,000 sheets are scanned.

Feed roller

Eject roller

Pick roller

Idler roller

Glass

Ultrasonic sensor

ATTENTION

Cleaning frequency may be increased depending on the condition of documents.

When the following types of documents are scanned, the scanner parts need to be cleaned

more frequently than indicated above.

 Coated paper

 Documents with large areas of printing

 Specially treated paper such as carbonless paper

 Paper containing large amounts of calcium carbonate filler

 Documents written in pencil

 Documents with insufficiently fused toner
