4.9 Configuring the Network Admin Settings

114

4.9.3 Setting a Central Admin Server (Details)

Set the scanner discovery to enable central administration.

1. Select [Scanner Central Admin Server Details] under [Network Admin].

 The [Scanner Central Admin Server Details] window appears.

2. Specify each item.

3. Press the [OK] button.

 The information entered is set.

Touch

Panel

Central Admin

Console

Main Page
