4.11 Configuring the e-Mail-Related Settings

128

4.11.3 Configuring Settings for Sending e-Mail

Configure the [Send e-Mail] window to send a scanned image by e-mail. Set the character

encoding used when e-mails are sent.

1. Select [Send e-Mail] under [e-Mail].

 The [Send e-Mail] window appears.

2. Specify each item.

3. Press the [OK] button.

 The information entered is set.

Touch

Panel

Central Admin

Console
