D.1 Installation Specifications
420
D.1 Installation Specifications
Item Specification
Dimensions (W × D × H) 300 × 232 × 172 mm (11.81 × 9.14 × 6.77 in.)
(This does not include the ADF paper chute or
other parts that stick out)
Weight 6.0 kg
LCD 8.4-in. XGA TFT LCD monitor
Touch panel Analog resistive touch panel
Keyboard On-screen keyboard
Interface Network LAN (1000BASE-T/100BASE-TX/10BASE-T) ×1
USB USB 2.0 ×2 (For keyboard and mouse)
Input power Voltage 100 to 240 V ±10%
Frequency 50/60 Hz
Power
consumption
(AC)
Operating 38 W or less
Energy-saving
mode
Power consumption value is different depending on
the "PART NO." that is printed on the label (*).
PA03706-Bxx1/Bxx3: 2.0 W or less
PA03706-Bxx5: 8.8 W or less
Power off 0.5 W or less
Operating
environment
Temperature Operating: 5 to 35 °C, Non-operating: -20 to 60 °C
Humidity Operating: 20 to 80%, Non-operating: 8 to 95%
Heating value Operating 33 Kcal/Hr or less
Energy-saving
mode
Heating value is different depending on the "PART
NO." that is printed on the label (*).
PA03706-Bxx1/Bxx3: 1.72 Kcal/Hr or less
PA03706-Bxx5: 7.57 Kcal/Hr or less
Power off 0.43 Kcal/Hr or less
(*): For details about the labels, refer to "7.5 Checking the Scanner Labels" (page
397).
HINT
The scanner is equipped with a LAN card that supports Wake On LAN. The power is not
turned on automatically by the Wake On LAN function after the power goes off abnormally,
such as in the event of a blackout.
