4.10 Setting the Authentication Server
117
■ LDAP Search Target
The search range and method for LDAP server searches are different according to the
LDAP server connection or the search base (DN) settings (Step 2 of "4.10.1 Setting the
Login LDAP Server" (page 115)).
The LDAP search targets in each setting are as follows:
For connecting with LDAP server (when [Active Directory] or [Other LDAP Server]
is selected in Step 2)
The following shows an example (where the domain name is example.com) for
[Search Base (DN)]. The italic text represents variable character strings.
Hereinafter, Active Directory is used as an example to describe search targets.
Example 1: When searching for (administrator, user A, user B)
CN=Users, DC=example, DC=com
Active Directory configuration is as follows:
example.com CN=Users
OU=department OU=section A
OU=section B
Administrator
User A
User B
User C
User D
User E
LDAP Tree: Example
Example 3
Example 2
Example 1
Example 4
