4.4 Configuring the System

4.4.5 Setting the Keyboard

1. Select [Keyboard Settings] under [Local Settings].

 The [Keyboard Settings] window appears.

2. Specify each item.

3. Press the [OK] button.

The information entered is set.

Touch

Panel

Central Admin

Console

ATTENTION

If [Off] is set for the on-screen keyboard display, you need to connect a hardware keyboard

additionally to enter characters.
