Fujitsu N7100 User Manual

4.8 Checking the Network Status
110
4.8.2 Checking the Network Operating Status
The operating status of the network can be checked.
If the information is not shown, the network may not be operating normally. Refer to "7.2
Network Connection Troubleshooting" (page 370), and check the settings.
1. Select [Network Status] under [Check Network Status].
 The [Network Status] window shows the status of the currently operating network
connection.
Touch
Panel
HINT
 If connection to LDAP server is not possible, try the following steps:
1. Disconnect the LAN cable.
2. Press the [Shutdown] button on the touch panel to turn the scanner off.
3. Press the power button to start the scanner with the LAN cable disconnected.
4. Enter a non-duplicated IP address.
5. Re-connect the LAN cable to the scanner.
 If the DHCP server cannot be reached when DHCP is set to [On], "169.254.X.X" is displayed
for the IP address (X can be any number from 0 to 255).

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
