Fujitsu N7100 User Manual

4.15 Viewing the Scanner Details
163
4.15.4 Managing the User Log
User log entries are saved in the scanner.
■ Viewing the User Log Details
The user log summary is shown in date/time order. Even if the [Region / Timezone] or
[Date / Time] settings are changed, the order of the log entries will not be changed.
1. Select [User Log] under [Status Details].
 The [User Log] window appears.
(Example of the Administrator Windows via the Admin Tool)
2. Select the user log you wish to view and press the [Details] button.
 The details of the selected log are displayed.
Pressing the [OK] button returns to the [User Log] window.
ATTENTION
 User logs may contain private information such as information on e-mail senders and fax
numbers, so care should be taken when managing such data.
 If a log file error is detected during scanner operation, the log file will be cleared and the log
entry "Error 81001004 Corrupted user log file was deleted." is recorded.
HINT
The [Date] format specified on the [Date / Time] window is used. For details, refer to "4.4.4
Setting the Date/Time" (page 84).
Touch
Panel

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
