4.4 Configuring the System

4.4.3 Setting the Region/Timezone

1. Select [Region / Timezone] under [Local Settings].

 The [Region / Timezone] window appears.

2. Specify each item.

3. Press the [OK] button.

 The information entered is set.

Touch

Panel

Central Admin

Console

HINT

If daylight savings time is on, daylight savings time and standard time switch automatically.
