7.2 Network Connection Troubleshooting
370
7.2 Network Connection Troubleshooting
If a network connection is not possible, first check the scanner status and system settings.
The following section provides information about general troubles that may occur when
connecting to a network.
If the cause of the problem is unknown or the problem persists, check the items in "7.4
Points to Check before Contacting Your FUJITSU Scanner Dealer" (page 394) and
contact your FUJITSU scanner dealer or an authorized FUJITSU scanner service
provider.
7.2.1 Basic Network Operation Tests
After the network has been setup, perform the following network operation tests on the
administrator window.
 Checking basic network operation with a Ping test
 Checking the network operating status
 Checking the NTP server settings by synchronizing the system time (if using an
NTP server)
 Checking the mail server by sending a test mail (if scanned data is to be sent as an
e-mail, by fax, or when requesting alert notifications by e-mail)
■ Checking Basic Network Operation with a Ping Test
Check the network connection status of the following computers and servers associated
with the network.
For details about the checking procedure, refer to "4.8.1 Checking the Network
Connection with a Ping Test" (page 109).
 Computer with Admin Tool installed
 Computer with Central Admin Console installed
 Computer with Central Admin Server software installed
 Computer with User Editor installed
 DNS server
 WINS server
 NTP server
 LDAP server
 SMTP server
 File server
 FTP server
 Print server
 SharePoint server
 Domain controller
 Proxy server
 SNMP server
ATTENTION
Depending on the server setting, there may be no response from a Ping test.

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
