A.4 Area not to be Perforated or Affixed with Other Papers

404

A.4 Area not to be Perforated or Affixed with

Other Papers

ADF feeding errors may occur while scanning if the document has any (punched) holes,

or if any other papers are attached in the area shown in the following figure.

Page top

Control point for scan

Front side

Feed

direction

Center of paper

Page bottom

25 mm 25 mm
