4.11 Configuring the e-Mail-Related Settings

126

4.11 Configuring the e-Mail-Related Settings

4.11.1 Setting the SMTP Server

1. Select [SMTP Server] under [e-Mail].

 The [SMTP Server] window appears.

2. Specify each item.

3. Press the [OK] button.

 The information entered is set.

Touch

Panel

Central Admin

Console
