7.4 Points to Check before Contacting Your FUJITSU Scanner Dealer

395

7.4.2 Error Status

■ Problem When Connecting to the Scanner via Computer

■ Document Feed Trouble

Info Findings

OS (Windows)

Internet Explorer

version

Admin Tool version

Displayed error

message

Info Findings

Paper type

Main purpose of use

Last cleaned on Year Month Day

Consumables last

replaced on

Year Month Day

Error message

details
