Fujitsu N7100 User Manual

4.14 Setting the Network Printers
157
(b-2) Registering a network printer and then selecting a driver for the network
printer
Enter a name in [Printer Alias] and [Printer name or IP address for the
network printer without print server], and select a driver name in [Driver
name for the network printer without print server].
For details about how to check the printer name or the IP address for a
printer, refer to "Checking the Printer Name or the IP Address for the
Printer (for Direct Printing)" (page 153).
For details about how to check the driver name for the printer, refer to
"Checking the Driver Name for the Printer (for Direct Printing)" (page
153).
5. Press the [OK] button.
 The window returns to the [Network Printer] window, and the registered network
printer is added to the network printer list.
HINT
On the touch panel and Admin Tool, you can select the driver name from a list box. On
Central Admin Console, since you need to enter the driver name directly, note the driver
name in advance.
HINT
 The default network printer alias will be the same as the alias selected from the network
tree. For details on changing the network printer alias later, refer to "Changing the
Network Printer Settings" (page 158).
 The authentication window may appear.

Fujitsu N7100 Specifications

General

Film scanning	No
Color scanning	Yes
Input color depth	- bit
Maximum scan size	216 x 3048 mm
Output color depth	24 bit
ADF scan speed (b/w, A4)	25 ppm
Optical scanning resolution	600 x 600 DPI
Duplex ADF scan speed (b/w, A4)	50 ipm
Black/white scanning color modes	Grayscale, Monochrome
Display	LCD
Scanner type	ADF scanner
Product color	Black
Display diagonal	8.4 \
Display resolution	1024 x 768 pixels
Scan to	E-mail, E-mail Server, Fax, File, FTP
Sensor type	CIS
Scan file formats	JPG, PDF, TIFF
Daily duty cycle (max)	400 pages
Supported network protocols	TCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity	50 sheets
Maximum scan area (ADF)	216 x 355.6 mm
Minimum scan area (ADF)	50.8 x 50.8 mm
ISO A-series sizes (A0...A9)	A4, A5, A6, A8
ISO B-series sizes (B0...B9)	B5, B6
Scanning media types supported	Business Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	40 - 209 g/m²
USB version	2.0
Standard interfaces	Ethernet, USB 1.1, USB 2.0
Input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Power consumption (standby)	1 W
Power consumption (typical)	38 W
Power consumption (PowerSave)	2 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	RoHS, ENERGY STAR
Bundled software	Scanner Central Admin Server
Ethernet LAN data rates	10, 100, 1000 Mbit/s

Weight and Dimensions

Depth	232 mm
Width	300 mm
Height	172 mm
Weight	6000 g
