4.18 Setting a Job Sequence
209
12. In the [Member Name] list of [Member Search], select the check box of a
user name, Active Directory group, or local account to be added to a job
group.
13. Press the [<<<] button.
The user, Active Directory group, or local account is added to the [Group
Membership List].
14. Press the [OK] button.
The number of members registered as job group members is shown in [Number
of Members] on the [Settings For Selected Group(s)] window.
15. Specify the members to be included in the job group in [Group Member
Settings].
16. Press the [Register] button.
A job group is added to the [Job Groups List] window.
HINT
To filter the LDAP List, refer to "Filtering the LDAP List" (page 213) for more details.
HINT
Up to 1,000 members can be added as job group members.
To delete a member added to the [Group Membership List], select the check box in the
[Member Name] list, and then press the [>>>] button.
HINT
If the [Include all LDAP users as members] check box is selected, all LDAP users are
included regardless of the selection of LDAP users in [Group Membership List].

Table of Contents

Other manuals for Fujitsu N7100

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu N7100 and is the answer not in the manual?

Fujitsu N7100 Specifications

General IconGeneral
Film scanningNo
Color scanningYes
Input color depth- bit
Maximum scan size216 x 3048 mm
Output color depth24 bit
ADF scan speed (b/w, A4)25 ppm
Optical scanning resolution600 x 600 DPI
Duplex ADF scan speed (b/w, A4)50 ipm
Black/white scanning color modesGrayscale, Monochrome
DisplayLCD
Scanner typeADF scanner
Product colorBlack
Display diagonal8.4 \
Display resolution1024 x 768 pixels
Scan toE-mail, E-mail Server, Fax, File, FTP
Sensor typeCIS
Scan file formatsJPG, PDF, TIFF
Daily duty cycle (max)400 pages
Supported network protocolsTCP/IP(IPv4 / IPv6), DNS, DHCP, SMTP, SMB, LDAP, NTP, FTP, HTTP, SNMP
Auto document feeder (ADF) input capacity50 sheets
Maximum scan area (ADF)216 x 355.6 mm
Minimum scan area (ADF)50.8 x 50.8 mm
ISO A-series sizes (A0...A9)A4, A5, A6, A8
ISO B-series sizes (B0...B9)B5, B6
Scanning media types supportedBusiness Card, Plain paper, Plastic Card, Post Card(JPN), Thick paper, Thin paper
Maximum ISO A-series paper sizeA4
Auto Document Feeder (ADF) media weight40 - 209 g/m²
USB version2.0
Standard interfacesEthernet, USB 1.1, USB 2.0
Input voltage100-240 V
Power supply typeAC
AC input frequency50 - 60 Hz
Power consumption (standby)1 W
Power consumption (typical)38 W
Power consumption (PowerSave)2 W
Operating temperature (T-T)5 - 35 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesRoHS, ENERGY STAR
Bundled softwareScanner Central Admin Server
Ethernet LAN data rates10, 100, 1000 Mbit/s
Weight and Dimensions IconWeight and Dimensions
Depth232 mm
Width300 mm
Height172 mm
Weight6000 g
