6.5 Replacing Parts

355

2. Remove the shaft.

Lift the right side of the roller first, then pull out the shaft from the slot on the

left.

3. Remove the brake roller from its shaft.

4. Attach a new brake roller on the shaft.

Insert the protrusion on the shaft into the slot.

Brake roller

Shaft

Brake roller

Shaft

Brake roller

Shaft

Protrusion

Slot
