GE LOGIQ P9 Service Manual

GEDRAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
Chapter 3 - Setup Instructions 3-61
NOTE: Reboot the system to activate any changes saved from this page.
IP-Address
Type the IP Address of the Ultrasound system. NOTE: IP stands for Internet Protocol. Every
device on the network has a unique IP address.
Subnet Mask
Type the subnet mask address. NOTE: The Subnet Mask is an IP address filter that eliminates
communication/messages from network devices of no interest to your system.
Default Gateway Type the default gateway address.
Network Speed
Select the network speed (Auto Detect, 10Mbps/Half/Full Duplex, or 100 Mbps/Half/Full Duplex/
1000Mbps/Auto-negotiate)
IPv6 (R3.0 or above) Select this box if your network system support and you want to use IPv6
IPv6 Address (R3.0 or above) Type IPv6 Address of the Ultrasound system
IPv6 Prefix Length (R3.0 or
above)
Type IPv6 Prefix Length
Default IPv6 Gateway (R3.0 or
above)
Type IPv6 Gateway address
Prmary DNS Server (R3.0 or
above)
Type Primary DNS Server address
Secondary DNS Server (R3.0
or above)
Type Secondary DNS Server address
Table 3-24 Wired Connection
Preset Parameter Description
IP-Address Displays currently configured IP address
Subnet Mask Displays currently configured subnet mask address
Default Gateway Displays currently configured default gateway address
MAC Address Unique network card address of the system.
Speed (Mbps) The performance of a network connection.
Connected (min The connection time with network.
Status Current network status.
IPv6 Address (R3.0 or
above)
Displays currently configured IPv6 address
IPv6 Prefix Length (R3.0 or
above)
Displays currently configured IPv6 Prefix Length
Default IPv6 Gateway (R3.0
or above)
Displays currently configured Gateway address
Primary DNS Server (R3.0
or above)
Displays currently configured Primary DNS Server address
Secondary DNS Server
(R3.0 or above)
Displays currently configured Secondary DNS Server address
Table 3-23 Wired Network Configuration
Preset Parameter Description

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
