GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

8-184 Section 8-47 - Replacement of MBOB

Section 8-47

Replacement of MBOB

8-47-1 Manpower

1 person, 20 minutes

8-47-2 Tools

Standard Phillips Screwdriver

8-47-3 Removal Procedure

1) Remove POWER CORD FIX BRKT and POWER CORD.

2) Remove REAR COVER ASSY.

Figure 8-225 Removing POWER CORD FIX BRKT and POWER CORD

Figure 8-226 Removing REAR COVER ASSY

REAR COVER ASSY
