Chapter 5 - Components and Functions (Theory) 5-13
Section 5-4
Software Options
5-4-1 Options
Following options are offered for LOGIQ P9/P7.
Table 5-8 Software Options
Software Options Description
Auto IMT automatically measures the thickness of the Intima Media on the far and near vessel walls.
Near Wall IMT is the distance between the trailing edges of the adventitia and intima; the
Far Wall IMT is the distance between the leading edges of the adventitia and intima.
B-Flow intended to provide a more intuitive representation of non-quantitative hemodynamics in
vascular structures. All B-Mode measurements are available with B-Flow active: depth,
distance along a straight line, % stenosis, volume, trace, circumference, and enclosed area.
Coded Contrast Imaging LOGIQ P9 only : Provides contrast imaging capability
CW Doppler Allows examination of blood flow data all along the Doppler Mode cursor rather than from
any specific depth. Gather samples along the entire Doppler beam for rapid scanning of the
heart. Range gated CW allows information to be gathered at higher velocities.
DICOM To enable DICOM connection to network device
Elastography Elastography shows the spatial distribution of tissue elasticity properties in a region of
interest by estimating the strain before and after tissue distortion caused by external or
internal forces. The strain estimation is filtered and scaled to provide a smooth presentation
when displayed.
Elasto QA Provides QAnalysis function in Elastography
Flow QA Provides QAnalysis function in Flow
LOGIQView provides the ability to construct and view a static 2D image which is wider than the field of
view of a given transducer. This feature allows viewing and measurements of anatomy that
is larger than what would fit in a single image. Examples include scanning of vascular
structures and connective tissues in the arms and legs.
Report Writer Provides output to external printers
Scan Assistant provides an automated exam script that moves you through an exam step-by-step. This
allows you to focus on performing the exam rather than on controlling the system and can
help you to increase consistency while reducing keystrokes.
Stress Echo provides an integrated stress echo package, with the ability to perform image acquisition,
review, image optimization, and wall segment scoring and reporting for a complete, efficient
stress echo examination.
TVI (Tissue Velocity Imaging) calculates and color-codes the velocities in tissue. The tissue velocity information is
acquired by sampling of tissue Doppler velocity values at discrete points
B Steer+ The user can enhance detectability of biopsy in the tissue without slanting whole B mode
image.
VOCALII You use VOCAL(Virtual Organ Computer-aided Analysis) to visualize and calculate the
volume of anatomical structures, such as a tumor lesion, cysts, and the prostate.
VCI Static VCI (Volume Contrast Enhanced Ultrasound) allows you to sweep smaller slices of data
with a higher volume rate.
TUI Tomographic Ultrasound Imaging (TUI) is a visualization mode which presents data as
parallel slices (planes) through the dataset.
4D 4D provides continuous, high volume acquisition of 3D images. 4D adds the dimension of
“movement” to a 3D image by providing continuous, real-time displays.
