8-166 Section 8-39 - Replacement of Bottom Fan Filter

Section 8-39

Replacement of Bottom Fan Filter

8-39-1 Manpower

1 Person, 3 minutes.

8-39-2 Tools

None Required.

8-39-3 Removal Procedure

1) Pull out bottom fan filter as following figure.

Figure 8-197 Removal of bottom fan filter

8-39-4 Installation Procedure

In Reverse Order.

8-39-5 Functional Check

Visual inspection Only.
