8-178 Section 8-45 - Replacement of battery pack for LP7-P9 R2 ext battery pack

7) Lift up POLARIS BATTERY PACK and disconnect BATTERY Harness from PWA. Then remove

POLARIS BATTERY PACK.

NOTE: Once replacing battery pack, all of battery packs (4 pcs) need to be replaced in same time.

8-45-4 Installation Procedure

NOTE: Once replacing battery pack, all of battery packs (4 pcs) need to be replaced in same time.

All components to be installed in reverse order of removal.

8-45-5 Functional Check

1) Turn on the circuit breaker.

Figure 8-212 Removing POLARIS BATTERY PACKS

Figure 8-213 Turning on circuit breaker
