GE LOGIQ P9 Service Manual

GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
2-6 Section 2-2 - General Console Requirements
2-2-6 System Specifications
2-2-6-1 Physical Dimensions of LOGIQ P9/P7
The physical dimensions and weight (without Peripherals) of the LOGIQ P9/P7 unit are summarized in
Table 2-6.
NOTE: Physical dimensions (especially height and depth) depend on control console and monitor positioning.
For more details refer to Chapter 5 - OPIO Positioning, on page 5-20.
2-2-6-2 Acoustic Noise Output
max. 50 dB(A)
2-2-6-3 Electrical Specifications
Please refer to Section 2-2-2-1 "LOGIQ P9/P7 Power Requirements" on page 2-3.
Table 2-6 Physical Dimensions and Weight (without Peripherals)
Height Width Depth Weight
1570 mm (max)
1375 mm (min) *
530 mm (console)
430 mm (Operator Panel)
740 mm 60 kg
* with low cabinet option

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
