GE LOGIQ P9 Service Manual

GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
9-4 Section 9-4 - Parts List Groups
Section 9-4
Parts List Groups
Figure 9-1 Console Views (R1 to R2.5)
Figure 9-2 Console Views(R3)
Table 9-4 Mechanical and user accessible parts
Item Part Group Name Table Number Description
100-
109-
Plastics Covers (Front/Sides/Rear)
Table 9-5 on page 9-6 Housing Covers
Plastics Covers (Front/Sides/Rear) (R3)
Table 9-6 on page 9-8 Housing Covers
200-
202
LCD Monitor
Table 9-7 on page 9-11 Monitor and its covers
301-
323
OPIO
Table 9-8 on page 9-15 User interface parts
401-
416
Nest Box Parts
Table 9-9 on page 9-19
Main board modules
Including front/back end boards

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
