GERAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

8-152 Section 8-29 - Replacement of Peripheral Cable Assy

8-29-2-5 Installation Procedure

Parts to be installed in reverse order of removal. But, refer to below procedure for cable ties.

Figure 8-179 Tie cables with the tie through the holes

8-29-2-6 Functional Check

Test 1: Print an image by pressing the button P1 on the operator panel. (P1 key should be configured

correctly. Refer to section 3-8-4 Adding Printer to the system)

Verify1: - Verify that image can be printed.

Verify2: - Verify that printed image has no distortion as compared the image on screen.

2 holes for fixing cable tie

Cable tie

Align the head of cable tie as shown
