3-20 Section 3-7 - Completing the Set Up
Section 3-7
Completing the Set Up
3-7-1 Connecting the Unit to a Power Source
The connection of the LOGIQ P9/P7 ultrasound unit to a power source should be performed by a
qualified person who has completed basic LOGIQ P9/P7 System User Training. Use only the power
cords, cables and plugs provided by or designated by GE to connect the unit to the power source.
!! CAUTION:
Prior to connect the LOGIQ P9/P7 unit to a power source, verify compliance with all electrical
and safety requirements. Check the power cord to verify that it is intact and of hospital-grade.
Products equipped with a power source (wall outlet) plug should be connected to the fixed
power socket that has a protective grounding conductor. Never use an adapter or converter to
connect with a power source plug (for example, a three-prong to two-prong converter).
!! WARNING:
The unit’s power must be supplied from a separate, properly rated outlet to avoid risk
of fire. Refer to Section 2-2-2-1 "LOGIQ P9/P7 Power Requirements" on page 2-3 for
rating information. The power cord should not, under any circumstances, be altered to
a configuration rated less than that specified for the current.
!! CAUTION:
Whenever disconnecting the LOGIQ P9/P7 system from the electrical outlet, always observe the
safety precautions. First unplug the main power cable from the wall outlet socket, then from the
unit itself. Remove by pulling on the cable connector - DO NOT pull on the cable.
!! CAUTION:
The LOGIQ P9/P7 requires all covers!
Operate this system only when all board covers and frame panels are securely in place.
The covers are required for safe operation, good system performance and cooling purposes.
