Chapter 8 - Replacement Procedures 8-189

Section 8-48

Replacement of MIO-B

8-48-1 Manpower

1 person, 20 minutes

8-48-2 Tools

Standard Phillips Screwdriver

8-48-3 Removal Procedure

1) Unscrew 12 screws and remove MIO BOX BRKT.

Figure 8-235 Unscrewing 12 screws
