GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 7 - Diagnostics/Troubleshooting 7-5

7-2-3 Request for Service (RFS) (R3 only)

7-2-3-1 Request for Service

1) Move the cursor to the GE icon and press the right-click, select “Contact GE”

2) The Request for Service (RFS) page is displayed

Figure 7-6 Contact GE

Figure 7-7 Contact GE – Request for Service
