8-188 Section 8-47 - Replacement of MBOB

10) Disassemble MBOB PWA from MIO-B PWA

8-47-4 Installation Procedure

All components to be installed in reverse order of removal.

8-47-5 Functional Check

Refer to section 4-4 for Functional Diag Test List.

Figure 8-234 Disassembling MBOB PWA
