GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 8 - Replacement Procedures 8-205

Section 8-52

Replacement of Probe Light assy

8-52-1 Manpower

1 person, 20minutes

8-52-2 Tools

Standard Phillips Screw driver

8-52-3 Pre work

1) Remove OPIO Panel assy (refer to section 8-14)

8-52-4 Removal Procedure

1) Remove probe light cable.

Figure 8-249 Remove of probe light cable from LP7P9 OPIO MAIN BOARD PWA
