GE LOGIQ P9 Service Manual

GERAFT LOGIQ P9/P7
D
IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL
3-66 Section 3-14 - Agent Configuration (R3 only)
Use Agent Configuration to:
• Edit and configure the following:
- Enterprise server, Select “Production” for install base. Select “Staging”for test purpose
- Enterprise host name in the agent
- Enterprise port number in the agent
- Proxy server, Proxy port in the agent, Consult institutions’ IT personnel for Proxy settings
- CRM number in the agent. The default CRM Number is same as the serial number prefixed with
"LP9P7".
-Display name in the agent
• Enter the user name and password for the proxy
• Reset the edited unsaved value
• Update contact details
For more information, see "Agent Configuration" of Common Service Desktop (R3 only) section on
Page 3-74.
NOTICE
!! NOTICE:
If you want to activate Request for Service (RFS), you need the verified CRM Number. The Serial
Number must be registered with only one CRM Number.

GE LOGIQ P9 Specifications

General

Type	Ultrasound System
3D/4D Imaging	Yes
Elastography	Yes
Connectivity	DICOM, USB, Ethernet, HDMI
Doppler Modes	Color Doppler, Power Doppler
Probes	convex, linear, phased array
Imaging Modes	M-Mode, Color Doppler, Power Doppler
Portability	Cart-based
Applications	Vascular, Cardiac, OB/GYN, Musculoskeletal
Weight	Approx. 80 kg
Touch Panel	10.1-in touchscreen
