GEDRAFT LOGIQ P9/P7

IRECTION 5604324, REVISION 11 DRAFT (JANUARY 24, 2019) SERVICE MANUAL

Chapter 5 - Components and Functions (Theory) 5-15

NOTE: In case the user scans any other barcodes in the manual below apart from “USB Serial” then the

barcode reader might be unable to scan the QR Code on the Pinpoint Needle or Patient or worklist. In

this case, please re-scan the “USB Serial” barcode.

Figure 5-7 USB Serial
