Chapter 5 - Components and Functions (Theory) 5-65
This table shows all the elements available on Run Diags with descriptions.
Table 5-26 Run Diags
Element DESCRIPTION
Service Menu Available service diagnostics in a diagnostics tree.
Engineering Menu Available engineering diagnostics in a diagnostics tree.
Clear All Resets the selections within the diagnostics tree.
Selected Diagnostics Diagnostics that have been selected.
Diagnostic Detail
Test Name Name of the diagnostic.
Last Execution Result Result of the diagnostic run.
Expected Execution Time Time expected to run the diagnostic.
Maximum Execution Time Maximum amount of time allowed to run the diagnostic.
Instruction Special instructions needed in order to perform the diagnostic.
Diagnostic Controls
Execution Mode
Way the diagnostic behaves when a failure occurs. Valid values are:
• Continue on Failure
• Finish Loop and Stop on Failure
• Stop on Failure
Loop Count Number of times to run the selected diagnostic.
Start Starts the selected diagnostic.
Stop Stops the selected diagnostic.
Reset Clears the current diagnostic information.
Total Progress
Current Progress Progress the current diagnostic.
Total Progress Progress for all of the selected diagnostics.
Diagnostic Results Summary
Diag Name Name of the diagnostic.
Date/Time Date and time of the diagnostic run.
Diag Run Time Amount of time taken to run the diagnostic.
Overall Status Current status of the diagnostic.
Pass/Fail
Whether the selected diagnostic passed or failed.
• Green - Diagnostic passed
• Red - Diagnostic failed
